AJ 160 Waterjet

Smallest jet in the Alamarin-Jet range

The AJ 160 waterjet is the smallest in the Alamarin-Jet range, with the majority of applications in luxury pleasure tenders and small commercial vessels. AJ 160 is the only commercially rated waterjet of its size available and as with all Alamarin-Jet products there are no limits on operational profiles.

Features include:

  • Conical impeller housing
  • Grease lubricated main bearing
  • Grease lubricated rear bearing
  • AJ ACU control system as standard
AJ 160 Waterjet
AJ 160 Waterjet
AJ 160 Waterjet
AJ 160 Waterjet
AJ 160 Waterjet
AJ 160 Waterjet
AJ 160 Waterjet

ISO

9001

ISO

14001

ISO

45001
AJ 160 Waterjet
Dimensions AJ 160
A 375 mm / 4,75 in
B 1166 mm / 45,95 in
C 510 mm / 20,08 in
D 300 mm / 11,82 in

Specifications

  • Pump type
    Mixed flow

  • Jet construction
    Aluminium / Stainless Steel

  • Max impeller diameter
    186mm / 7.3″

  • Max impeller shaft RPM
    5000 1/min

  • Max input power
    100 kW / 136 HP

  • Jet weight
    38kg / 84lbs

  • Reverse deflector control
    Mechanical or ACU

Contact us for more information

If you want to learn more about this or our other models for your particular specifications and application, we are here to help you.
