AJ 180/185 Waterjets

Used in both leisure and commercial applications

The AJ 180 and AJ 185 are often used in both leisure and commercial applications, with the majority of applications in luxury pleasure tenders and small commercial vessels, often requiring SOLAS certification. As with all Alamarin-Jet products there are no limits on operational profiles.

Features include;

  • Conical impeller housing
  • Grease lubricated main bearing
  • Grease lubricated rear bearing
  • AJ ACU control system as standard
AJ 180 / 185 Waterjets
AJ 180 / 185 Waterjets
AJ 180 / 185 Waterjets
AJ 180 / 185 Waterjets
AJ 180 / 185 Waterjets
AJ 180 / 185 Waterjets
AJ 180 / 185 Waterjets

ISO

9001

ISO

14001

ISO

45001
AJ 180 / 185 Waterjets
Dimensions AJ 180 AJ 185
A 379 mm / 14.9 in 423 mm / 16.7 in
B 1307 mm / 51.5 in
 1369 mm / 54.1 in
C 530 mm / 20.9 in 530 mm / 20.9 in
D 306 mm / 12 in 306 mm / 12 in

Specifications

  • Pump type
    Mixed flow

  • Jet construction
    Aluminium / Stainless Steel

  • Max impeller diameter
    192mm / 7.6″
    197mm / 7.8″

  • Max impeller shaft RPM
    5000 1/min

  • Max input power
    110 kW / 150 HP
    120 kW / 163 HP

  • Jet weight
    48kg / 106lbs
    50kg / 110lbs

  • Reverse deflector control
    Mechanical or ACU

Contact us for more information

If you want to learn more about this or our other models for your particular specifications and application, we are here to help you.
